SPECIAL OFFER – PIE1066 + 6V solar panel

• PIR sensor (motion sensor):
  • Detection angle: 60°
  • Detection distance: up to 49.2 feet (15 meters)
  • Adjustable sensitivity: Low | Medium | High | Auto
• Infrared flash:
  • 26 invisible LEDs
  • Wavelength: 940 nm
  • Range: up to 49.2 feet (15 meters)
  • Automatic IR Flash (activated according to brightness)
• Field of view: 84°
• Trigger speed: approx. 0.4 second
• Capture modes:
  • Still images
  • Videos
  • Still images + videos (photo and video clip are both captured for each trigger)
• Image resolution: 2MP | 5MP | 8MP | 16MP
• Multi-shot:
  • if photo resolution is 2 or 5MP: adjustable from 1 to 3 photos per trigger
  • if photo resolution is 8MP: adjustable from 1 to 2 photos per trigger
  • if photo resolution is 16MP: only 1 photo per trigger
• Image file format: JPG
• Video resolution: VGA | WVGA | HD 720p | FULL HD 1080p
• Video length: programmable| 10, 15, 20, 30 seconds, 1, 2 or 2 minutes
• Audio recording on videos: programmable (ON | OFF)
• Video file format: AVI (MJPG)
• PIR detection mode: the camera will take photos or videos when triggered by the PIR sensor (motion sensor) detecting activity in the area it covers
• Time Lapse mode: the camera will take photos or videos automatically at your choice of interval (PIR sensor deactivated in this mode – no motion detection)
• Photos stamped with time, date, lunar phase, temperature, camera ID
• Memory support: micro SD card from 4GB up to 32GB, class 10 minimum (not supplied). You can purchase micro SD cards from the present website at any time.
• Programmable identification number of the device: allows you to identify from where and from wich camera the photos are (useful when you have more than one device)
• Programmable password

Reliable and efficient

• 2-year warranty
• Weather resistant (IP66)
• Compatible with external power (6V/2A)

PIE1066 trail camera specifications

• Weight: 191 g (without batteries) | 284 g (with batteries)
• Dimensions: 116 x 90 x 55 mm – Compact and very easy to conceal
• Power: 4 x  AA batteries (alkaline, lithium or rechargeable Ni-MH – batteries not supplied) – You can purchase alkaline or Ni-MH batteries at any time on this website.
• External DC port (6V/2A) for solar panel or power adaptor – You can purchase those products at any time on this website.
• 1.36″ color LCD screen

Listed below are some useful pointers on how to use your trail camera to get the best results

• Mount the camera about 1.5~2 m (5~6 ft) high with the camera pointed at a slight downward angle.
• Mount the trail camera facing north or south not east or west as the rising ans setting of the sun could produce false triggers and overexposed images.
• If you’re covering a trail, face the camera down or up the trail.
• Clear out any brush or weeds in front of the trail camera. These can cause false triggers due to temperature and motions disturbances in front of the camera (especially on windy days).

6V solar panel features

• Built-in battery: 2 pieces 3.7V 18650 lithium batteries, 5200mAh
• Maximum output: 6V / 1A
• Output over-current protection
• Short-cut protection
• Solar panel output power: 1.6W
• Solar panel charging current: 320mA
• Start-up modes:
  • automatic start when more than 0.2W solar power output is detected
  • manual start
  • loading detected
• Triple battery protection:
  • over discharge protection: stops discharging when voltage is lower than 3.3V
  • over current protection: stops charging when voltage is higher than 4.2V
  • temperature protection: stops charging when temperature is higher than 65°C or lower than 2°C
• Charging methods:
  • with solar energy
  • with external power supply (5V – micro USB port)

Reliable and efficient

• Waterproof design suitable for outdoor use
• Its compact design makes it easy to take with you anywhere you go
• Built-in compass at the back of the panel to facilitate and optimize orientation
• Comes with an adjustable ease-to-use mounting bracket
• Triple battery protection

6V solar panel specifications

• Dimensions: 140 x 85 x 25mm / 5.5 x 3.3 x 1in.
• Weight: 290g / 10.2oz.
• Output cable length: 3m / 10ft.
• Watertight
