Cellular trail camera – model PIE1052 – 4G

• Multi-operator SIM card included:

• • The SIM card is already fitted in the product at time of purchase
  • You can choose between 5 photo and video transmission plans, including one FREE (4 commitment-free monthly plans, 1 yearly plan)
  • Multi-operator SIM card: the device searches for the strongest signal – Click here to download the network and countries covered
  • The device only works with the supplied SIM card.
• The photos or video previews are sent to a Cloud storage:
  • Your Cloud storage is accessible at any moment thanks to the free app (iOS/Android – app name: PIE Cloud)
  • Resolution of the photos sent to the Cloud: 640 x 480 pixels
  • Video previews: 3-second previews made of at least 10 photos
  • You can receive HD photos on request (1920 x 1440 pixels)
• In the Cloud, photos can be filtered using tags:
  • list of tags already available in the app (boar, human, vehicule, etc.)
  • You can also create your own tags
• Field of view: 100°
• PIR sensor (motion sensor):
  • Detection angle: 100°
  • Detection distance: up to 65 feet (20 meters)
  • Adjustable detection sensitivity: low | medium | high
• Infrared flash:
  • 60 invisible black LED
  • Range: up to 65 feet (20 meters)
  • You can turn off part of the LED:
    • allows you to avoid overexposed night photos/videos
    • useful if you plan to place the camera at very close range to the subject you want to photograph or film.
  • Automatic IR Flash (activated according to brightness)
  • Adjustable night mode: a shorter or longer exposure time allows you to extend or minimize the IR flash range
• Capture modes:
  • Still image: from 1 to 2 images per trigger
  • Video with audio recording: fixed length (10 seconds)
  • Still image + video with audio recording: a still photo and a video clip are both captured for each trigger

• Image resolution: 8 MP | 12 MP | 24 MP
• Image file format: JPEG
• Video resolution: WVGA | HD 720P | FULL HD 1080P
• Video file format: MOV
• You can setup and activate the camera remotely thanks to a free mobile app (Android/iOS – app name: PIE Cloud)
• Remote antenna supplied:
  • very useful in areas where the network is weak
  • antenna height: 22 cm – cable length: 2 m – magnetic base
• PIR detection mode: the camera will take photos or videos when triggered by the PIR sensor detecting activity in the area it covers
• Time Lapse mode: the camera will take photos or videos automatically at your choice of interval
• Built-in GPS antenna to add geotag stamp on photos
• Date, time, temperature, moon phase, identification number, battery level and GPS coordinates can be pirnted on the photos
• Memory support: SD card or micro SD card with adapter from 4GB up to 32GB, class 10 minimum (not supplied). You can purchase micro SD cards with adapter from the present website at any time.
• Cycle recording on the SD card:
  • User programmable: ON/OFF
  • When the SD card will be full, the camera will continue to record new photos/videos by deleting the oldest photos/videos.
• Identification number of the device: programmable – allows you to identify from where and from which camera the photos are – Very useful if you have several devices
• Password: programmable

Reliable and efficient

• 2-year warranty
• Weather resistant (IP66)
• Trigger speed: approx. 0.35 seconds

PIE1052 cellular trail camera specifications

• Weight: 418 g (without batteries) – 696 g (with batteries)
• Dimensions: 148 x 116.5 x 75.5 mm
• Remote antenna supplied
• Power: 12 x AA batteries (alkaline or Ni-MH rechargeable – not supplied) – You can purchase those batteries at any time on this website.
• Optional external power supply: 12V power pack or 12V solar panel – You can purchase those products at any time on this website.
• 2.4″ color TFT screen: for easy set up and replay photos/videos
• Built-in 2.0 USB port for images/videos download (files on the memory card)

Listed below are some useful pointers on how to use your trail camera to get the best results

• Mount the camera about 1.5~2 m (5~6 ft) high with the camera pointed at a slight downward angle.
• Mount the trail camera facing north or south, not east or west, as the rising ans setting of the sun could produce false triggers and overexposed images.
• If you’re covering a trail, face the camera down or up the trail.
• Clear out any brush or weeds in front of the trail camera. These can cause false triggers due to temperature and motions disturbances in front of the camera (especially on windy days).
• Check the power level of the batteries.
• Make sure the memory card is properly inserted and have sufficient available space.
• verify time and date are correct.
• Make sure to turn the camera ON before you leave (switch in the ON position).
